JBL Professional

SCS 12

Sinema Hoparlörleri

Marka:	JBL Professional
Ürün Kodu:	SCS 12
Kategori:	Hoparlörler
Barkod:

TEKNİK ÖZELLİKLER
DETAYLAR
DÖKÜMANLAR

ÖZELLİKLER

TEKNİK ÖZELLİKLER

Frequency Response (-10dB)	55 Hz – 20 kHz
Frequency Response (±3 dB)	70 Hz – 20 kHz
Coverage Pattern	100° x 100°
Directivity Factor (Q)	10.1 (1 k – 16 kHz)
Directivity Index (DI)	9.5 dB (1k – 16 kHz)
System Power Rating	400 W (1600 W peak), 2 hrs. 250 W (1000 W peak), 100 hrs
Sensitivity (2.83V @ 1m)	96 dB (Ave. 70 Hz – 20 kHz)
Maximum SPL (1m)	122 dB (peaks of 128 dB) @ 1m
Crossover Network	1.8 kHz, 3rd order (18 dB/oct) high-pass plus conjugate to HF, 2nd order low-pass to LF
Nominal Impedance	8 ohms
LF Driver	Kevlar-reinforced cone, 75 mm (3 in) voice coil.
HF Driver	25 mm (1 in) diaphragm and voice coil diameter, high temperature polymer diaphragm, patented design, fluidcooling.
HF Driver Protection	Minimum audibility SonicGuard™ HF overload protection
Enclosure	ABS with Glass enclosure, heavily braced
Attachment	Two M10 points for included U-bracket. M6 secondary safety attachment point on back panel.
Grille	Corrosion-resistant zinc-rich steel grille.
Dimensions	402 x 402 x 445 mm (15.8 x 15.8 x 17.5 in), cabinet 470 mm (18.5 in) depth with gland nut 502 mm (19.75 in) including bracket extending to back
Colors	Black
Net Weight	14.0 kg (31.0 lb), 16.8 kg (37.0 lb) with U-Bracket
Shipping Weight	19.5 kg (43.0 lb)
Included Accessories	U-bracket, Steel

DETAYLAR

Spatially Cued Surround Loudspeaker 2-Way Coaxial with 12" LF

The SCS 12 is a coaxial-driver, 2-way, fullrange cinema surround loudspeaker ideal for multi-channel surround formats and is designed for overhead installation as well as for standard on-wall installations.
