Dimensions (HWD) :1 4/5” x 17” x 9 1/8” (45.15 mm x 431.80 mm x 231.64 mm)
Weight:6.08 lb. (2.758 Kg)
Memory:Memory Card: 8 GB SD, NVRAM: 1 MB, DDRAM: 512 MB, Note: Supports external USB Solid State Drives
Power Consumption :Active Power Consumption: 4.2 W
AxLink Port :(1) 4-position 3.5mm Screw Terminal, provides data and power to external AxLink control devices
AxLink Indicator :(1) AxLink LED (green) indicates the state of the AxLink port
RS-232 Port :(1) 5-position 3.5mm Screw Terminal, NetLinx Port 2, XON/XOFF (transmit on / transmit off), CTS/RTS (clear to send/ready to send), 300 - 115,200 baud
Serial Indicator :(2) sets of LEDs (red/yellow) indicate when serial Ports 1 and 2 are transmitting and receiving data
IR/Serial :(2) 2-position 3.5mm Screw Terminal, 2 IR Transmit / 1-way Serial ports, NetLinx Ports 11-12, Support high-frequency carriers up to 1.142 MHz, 2 IR/Serial data signals can be generated simultaneously
IR/Serial Indicators :(2) LEDs (red) indicate when each of the IR/Serial ports (11-12) are transmitting control data
I/O Channels :(4) One 6-position 3.5mm Screw Terminal, 4-channel binary I/O port for contact closure with each input being capable of voltage sensing, NetLinx Port 22, Channels 1-4
I/O Indicator :(4) LEDs (yellow) indicate each of the I/O channels (1-4) are active
