Crown

IT4X3500HDB

8 Ohm Amfiler
Marka:
Ürün Kodu:
Kategori:
Barkod:

  • TEKNİK ÖZELLİKLER
  • DETAYLAR
  • DÖKÜMANLAR
ÖZELLİKLER
TEKNİK ÖZELLİKLER
Channels 4 inputs, 4 outputs (Analog, AES 3, VDrive, CobraNet)
Sensitivity Adjustable in 0.1dB increments from 1.28Vrms to 8Vrms
Damping Factor > 5000
Signal to Noise Ratio ≥ 108dB
THD (full rated power, 20 Hz - 20 kHz) 0.35%
Frequency Response ± 0.25dB
Intermodulation Distortion (from 0 dB down to -40 dB) 0.06%
Crosstalk > 80dB
Common Mode Rejection > 80dB typical
Dimensions 3.3" x 19" x 16.95" (8.9 cm x 48.3 cm x 43.1 cm)
Net Weight 29 lbs (13.2 kgs)
Power Connector 32A powerCON (on amp) - L6-30 plug (into wall)
DETAYLAR
DETAYLAR

The I-Tech 4x3500HD amplifier is the industry's first high-powered tour sound amplifier featuring four inputs, Analog, AES3, and CobraNet™, fully routable to any one of 4 outputs.  Each channel features a complete compliment of OMNIDRIVEHD™ Processing, including the acclaimed LevelMAX™ Limiter Suite, and support for linear phase FIR filters as used in the latest JBL V5 loudspeaker tunings.  Combine that with Crown's patented Class-I technology delivering uncompromising power output across all four channels, and it's easy to see why the I-Tech 4x3500HD is the flagship tour sound amplifier from Crown.

HD4 Power Matrix
