Crown

DSI 6000

8 Ohm Amfiler
Marka:
Ürün Kodu:
Kategori:
Barkod:

  • TEKNİK ÖZELLİKLER
  • DETAYLAR
  • DÖKÜMANLAR
ÖZELLİKLER
TEKNİK ÖZELLİKLER
Voltage Gain 37.1 at 1 kHz
Frequency Response +0/-1 dB from 20 Hz to 20 kHz at 1 watt into 4 ohms
Load Impedance Safe with all types of loads. Rated for 2 to 8 ohms in Stereo mode, 4 to 16 ohms in Bridge-Mono mode. DSi A1 (100V version) is rated for 4 to 8 ohms in Stereo mode, 8 to 16 ohms in Bridge-Mono mode.
Sensitivity at 8 ohm rated output: 1.4V, at 4 ohm rated output: 1.3V, At 2 ohm rated output: 1.1V
Signal to Noise Ratio (below rated 8-ohm power at 1 kHz) 100db (A-weighted)
Damping Factor Better than 500 from 20 Hz to 400 Hz
Crosstalk > 70 dB below rated power, 20 Hz to 1 kHz, A-weighted
Input Stage Input is electronically balanced and employs precision 1% resistors
Input Impedance (nominal) 20 k ohms, balanced; 10 k ohms, unbalanced
AC Line Voltage and Frequency Configurations Available 100V, 120V, 220-240V, 50/60 Hz
IEC Power Connector 20A
DETAYLAR
DETAYLAR

Engineered from the ground up for unmatched quality and performance, the Crown® DSi Series of power amplifiers offers four models of 500W, 800W, 1,200W, and 2,100W per channel at 4 ohms. Onboard digital signal processing includes crossovers, EQ filters, delay and output limiting. Rear panel HD-15 connector provides easy input/output connectivity between DSi amplifiers and the new DSi-8M System Monitor. At the touch of a button, Crown’s DSi cinema amplifiers deliver perfectly matched performance with each award-winning JBL ScreenArray® system, making this the ultimate cinema solution.

Power Matrix
