| Frequency Response (-10dB) |
55 Hz - 19.5 kHz
|
| Coverage Pattern (-6 dB) |
Horizontal: 60; Vertical: 60
|
| System Input Power Rating1 |
Passive: 1250 W Continuous (IEC / 100 hour) Active: LF: 1250 W Continuous (IEC / 100 hour) HF: 100 W Continuous (IEC / 100 hour)
|
| Maximum Peak Output2 |
136dB (Preset: VTX M20 FR)
|
| System Latency3 |
3.33ms
|
| System Processing |
Crown Audio I-Tech HD Series Crown Audio I-Tech 4x3500HD
|
| System Impedance |
Passive: 4 ohms Active: LF: 4 ohms, HF: 8 ohms
|
| Low Frequency Transducer |
2 x 2261H, 254 mm (10 in) diameter, dual 76 mm (3 in) diameter voice coil, NDD®, Direct Cooled™
|
| High Frequency Transducer |
1 x D2430H, D2 dual diaphragm, dual 76mm (3 in) diameter voice coil
|
| Monitor Angle |
30 degrees
|
| Construction |
18 mm, 11-ply Finnish birch plywood
|
| Grille |
Powder Coated 14 gauge hex-perforated steel with acoustically-transparent black cloth backing
|
| Input Connectors |
Passive: Neutrik® Speakon® NL-4 (4x): Selectable: Pins 1 ± or Pins 2 ± Active: Neutrik® Speakon® NL-4 (4x): Pins 1 ± (LF) | Pins 2 ± (HF)
|
| Dimensions (H x W x D) |
342.9 mm x 575.0 mm x 515.3 mm (13.6 in x 22.6 in x 20.3 in)
|
| Net Weight |
23 kg (51 lbs)
|
