3600 Serisi İçin Delege Mikrofonu
Technical Specifications
Electrical
Headphone connection
-
Frequency response 40 Hz to 16 kHz
-
Earphone load impedance >16 Ohm
-
Earphone output 10 mW
Recommended microphone type
-
Transducer Electret-condenser
-
Polar pattern Uni-directional
-
Operating voltage 5 VDC
-
Sensitivity -46 dBA at 680 Ohm (0 dB = 1 V/Pa at 1 kHz)
-
Frequency response 80 Hz to 18 kHz
-
Input impedance 2 kOhm
-
Directivity 0°/180° > 20 dB (1 kHz)
-
Equivalent noise 25 dBA (SPL)
-
Maximum sound pressure level 125 dB (THD<3%)
Interface data
-
Connector 2 x Ø 3.5 mm stereo jack for headphone
Mechanical
-
Mounting Tabletop mounting
-
Dimensions (h x w x d) (w/o Mic.) 62 x 156 x 125 mm
-
Weight 0.74 kg
-
Color Gray/Silver
Ordering Information
-
HCS-3632CB Digital Conference System Chairman Unit
-
(tabletop, speech timer & request-to-speak indicator, gray)
-
HCS-3632CB_S Digital Conference System Chairman Unit
-
(tabletop, speech timer & request-to-speak indicator, silver)
