JBL Professional

CONTROL 227C/T

Tavan-İçi Hoparlörler
Marka:
Ürün Kodu:
Kategori:
Barkod:
  • TEKNİK ÖZELLİKLER
  • DETAYLAR
  • DÖKÜMANLAR
ÖZELLİKLER
TEKNİK ÖZELLİKLER
Frequency Range (-10 dB) 43 Hz - 19 kHz
Transformer Taps 68W, 34W, 17W (& 8.5W @ 70V)
Sensitivity (1W, 1m) 90 dB (1 kHz - 16 kHz)
Coverage Angle 120° conical, constant directivity
Frequency Response (-3 dB) 75 Hz - 17 kHz
Drivers LF Driver: 165 mm (6.5 inch)
HF Driver: compression driver, 25 mm (1 inch) coil
Safety Agency Suitable for use in air handling spaces per UL1480, UL2043, NFPA90 & NFPA 70 when installed with UL listed backcan such as JBL MTC-200BB6 or MTC300BB8. S7232/UL Listed, Signaling Speaker. Transformer UL registered per UL1876. In accordance with IEC60849/EN60849.
Dimensions (H x Dia) Ø 305 mm (12 in) round baffle x depth from back of baffle of 147 mm (5.8 in)
Net Weight (each) 5.2 kg (11.5 lb)
Shipping Weight (pair) 6.6 kg (14.5 lb)
Power Rating See transformer taps
Rated Maximum SPL (1m) 108 dB (top 70V/100V tap)
Input Connectors Screw locking barrier strip for bare wire
Color White
Backcan formed steel (wood-lined; accessory)
Baffle/Rim Metal, round, driver pre-mounted to baffle, ported.
Ceiling Cutout Size 310 mm (12.2 in) diameter (for MTC-200BB6 backcan)
Included Accessories Ported baffle pre-attached, transformer on 227CT
Optional Accessories MTC-200BB6 Back Can (0.7 cu ft) MTC-RG6/8 Grille MTC-TB6/8 Tile Bridge Also compatible with MTC-300BB8 backcan (1.0 cu ft)
Plenum Usage Yes, with accessory backcan
DETAYLAR
DETAYLAR

6.5" Coaxial Ceiling Loudspeaker with HF Compression Driver with 60W Multi-Tap Transformer

The JBL Professional Control 227C and CT are premium in-ceiling professional loudspeakers designed for applications requiring superior quality sound in-ceiling mount applications.
